Verhoef Gangway Systems

Safe and reliable under all circumstances

Verhoef Access Technology has designed and manufactured more than 850 shore-based access systems for Oil and Gas terminals to nearly 70 countries all over the world. Since the supply of the first Gangway System in 1966, we have developed a large number of standard designs, which are flexible to be adapted or tuned in accordance with the specific requirements of the client.

Basically there are three main designs:

  • the tower type, with a telescopic gangway that moves vertically along the tower by means of a lift platform. Because of its lift platform, the gangway-tower can cover ship deck levels from Small Barges up to Ultra Large Crude Carriers in combination with ship movements resulting from tidal, loading/unloading and heave motions.
  • the column type, with a telescopic gangway at a fixed height. The column type is suitable for reaching ship deck levels from well below up to a maximum of approximately 18 meter (54 feet) above jetty deck.
  • the riding ladder can be used when the variation in ship’s deck levels is limited and sufficient space on the jetty deck is available.

Moreover, Verhoef produces portable gangways, bulwarkladders, cabin stairs and mobile maintenance platforms for aircrafts, and mobile passenger bridge systems. For all products we manufactured we offer a lifetime extension programme.

Gangway Tower

The Verhoef Gangway Tower has a telescopic gangway that vertically moves along the tower by means of a lift platform. As a result, the gangway-tower can cover ship deck levels from Small Barges up to Ultra Large Crude Carriers, in combination with the ship movements...

Read more »

Gangway Column

The column has a turnable platform at a fixed height which can be reached by access stairs mounted to the side of the main structure. The telescopic gangway is mounted to the turnable platform and after positioning on the vessel’s deck will freely follow all movements...

Read more »

Riding Ladder

The Riding Ladder Systems vary in their design from a simple hand powered up to a fully hydraulic or electric powered design. Normally, the riding ladder system has a gangway with a fixed length. The sway movement of the vessels is compensated by the riding...

Read more »

Ships Gangways

Verhoef manufactures alodised aluminium gangways that provide a safe link between the ship and the shore. We have standard types in our range, you can find their specifications in the scheme below. However, it is also possible to have a gangway custom-built for you, exactly according to the specifications...

Read more »

Bulwark Ladders

Verhoef produces two types of bulwark ladders, either with antislips steps (type A) or flat checkerplate steps (type B), designed for bulwarkheight between 1-1,20 mtr. Both types are entirely made of seawaterresistant aluminium alloy and alodised as extra protection against corrosion.  The Verhoef bulwark ladders...

Read more »

Cabin stairs and mobile maintenance platforms

In airplane maintenance, safe access is of vital importance. As maintenance personnel has to position their access equipment around the airplane, access stairs and mobile maintenance platforms should be lightweight, easy to operate and maintenance free. Movement by hand or electric or compressed air, we design...

Read more »

Mobile Passenger Bridge Systems

For safe access to cruise vessels, Verhoef designs, builds and installs passenger bridge systems. Based on the technology used for ship to shore access systems for oil and gas terminals, Verhoef builds passenger bridges at customer specification, adjusted to existing situations or integrated in the...

Read more »

Lifetime extension programme

Verhoef Access Technology sets great value to the performance of the equipment supplied and has therefore set up a Lifetime Extension Programme (LTEP) for existing access systems and gangways. The Lifetime Extension Programme starts with a thorough inspection by one of our inspection engineers. Our engineer...

Read more »
